Cat 6 Ethernet LAN Cable

المميزات الرئيسية

• Cat 6 Ethernet network cable for high speed data installations
• Supports 1 Gbps Ethernet over 100 metres standard length
• Handles 10 Gbps over shorter runs (up to 55 metres typical)
• Suitable for IP CCTV camera installations and PoE applications
• Backward compatible with Cat 5 and Cat 5e equipment
• 4 twisted pair construction with internal separator for crosstalk reduction
• Available in solid copper and copper clad alternatives (clearly labelled)
• Indoor and outdoor jacketed variants stocked
• Standard reel lengths for project work

Why Cat 6 Has Replaced Cat 5e for Most New Installations

Cat 5e cable was the workhorse of office networking for years. It handled the 1 Gbps speeds that most office equipment runs at, it was inexpensive, and it was easy to terminate. Most network installations from 2005 to about 2015 used Cat 5e and worked fine.

Then a few things changed. IP CCTV cameras became standard equipment with the introduction of MoI mandated CCTV regulations across KSA. Many of these cameras need PoE (Power over Ethernet) to receive both power and data through a single cable. Office networking equipment started supporting 10 Gbps speeds. Smart building systems started running larger amounts of data through structured cabling.

For all of this, Cat 5e is on the edge of its capability. Cat 6 has more headroom. It supports 1 Gbps comfortably with margin to spare. It handles 10 Gbps over the shorter runs typical of building wiring. It performs better with PoE and PoE+ powered devices. And it future proofs the installation for whatever bandwidth requirements come next.

For most new installations in Saudi Arabia, Cat 6 is now the working standard. We stock it because that’s what installers actually need.

Why Solid Copper Cat 6 Cable Is Essential for Reliable Networking

This is where buyers get burned. Cheap “Cat 6” cable on the market is often copper clad aluminium (CCA), which is aluminium wire with a thin copper coating. Real Cat 6 cable is solid copper conductors throughout.

CCA cable looks identical to solid copper from the outside. It’s cheaper. And it works for a while. But CCA has higher resistance than solid copper, which means more voltage drop on PoE runs (cameras and equipment receive less power than they should), more heat generation under PoE load (creates fire risk on long runs), and shorter service life.

For PoE camera installations specifically, CCA cable is a real problem. It can deliver enough power to start the camera but not enough to run it under all conditions, leading to intermittent failures that are hard to diagnose. For commercial structured cabling that has to meet building standards, solid copper is required.

The Cat 6 cable we stock is clearly labelled as solid copper or CCA where applicable, so installers can choose with full information. For any PoE installation, CCTV deployment, or commercial structured cabling, solid copper is the right specification.

When and Where to Use Cat 6 Cable for Networking

IP CCTV camera installations: connecting cameras to NVR recorders with both data and PoE power on the same cable. This is one of the largest current applications given the MoI CCTV requirements.

Office structured cabling: connecting workstations to network switches in office, retail, and commercial premises.

Smart building systems: HVAC BMS controllers, lighting control systems, access control systems, and other building automation that increasingly runs over IP networks.

VoIP phone systems: powering and connecting IP phones across office installations.

Wireless access point distribution: connecting WAP devices to network switches with PoE power.

Server room and data centre patching: shorter runs between switches, patch panels, and equipment.

Home networking and smart home installations: increasingly common in modern villas with networked equipment.

How to Choose Between Indoor and Outdoor Cat 6 Cable

Standard Cat 6 has a PVC jacket designed for indoor use. The jacket is rated for typical indoor environmental conditions but degrades under UV exposure and moisture over time.

For outdoor runs (between buildings, exterior CCTV cameras, anywhere the cable is exposed to sun and weather), outdoor rated Cat 6 with UV resistant jacket is needed. We stock outdoor jacketed variants for these applications.

For runs inside conduit underground or in similar protected outdoor pathways, regular indoor cable can sometimes be used, but verify with the project specification before installing.

Where Cat 6 Cable Excels in Networking Applications

• IP CCTV camera networking and PoE power delivery
• Office workstation cabling and structured cabling work
• Building network infrastructure
• Smart building and BMS networking
• VoIP phone system installations
• Wireless access point distribution
• Server room patching and equipment connections
• Industrial Ethernet networking
• Home networking and villa structured cabling
• Hotel and hospitality network installations
• School and educational facility networks

المواصفات الفنية

Why Cool.sa is the Trusted Source for Cat 6 Cable in Saudi Arabia

في Cool.sa We supply Cat 6 Ethernet cable to network installers, IT contractors, security camera installers, electrical contractors, and FM teams across Saudi Arabia. We stock both indoor and outdoor variants, and we clearly label solid copper versus CCA so installers can choose with full information. We offer contractor pricing on full reel orders and project quantities. And we stock the matching network accessories (RJ45 connectors, patch panels, network testers, surveillance cameras) alongside the cable so a complete network installation order ships in one delivery.

الأسئلة الشائعة

Q1. What’s the difference between Cat 5e and Cat 6?

Cat 6 has tighter pair twists, an internal separator between pairs, and supports up to 250 MHz bandwidth versus 100 MHz for Cat 5e. In practical terms, Cat 6 handles 10 Gbps over shorter runs and provides better PoE performance. For new installations, Cat 6 is the current standard.

Q2. Do I need Cat 6A instead of Cat 6?

Cat 6A supports full 10 Gbps over 100 metre runs versus Cat 6 at up to 55 metres for 10 Gbps. For most building wiring, Cat 6 is sufficient. For data centre cabling or specialised high speed runs, Cat 6A may be required.

Q3. Is solid copper really worth the extra cost over CCA?

For PoE installations and commercial structured cabling, yes. CCA cable has higher resistance which causes problems with PoE power delivery. Cheap CCA cable can also fail building inspection in commercial work. For non PoE residential use, CCA might work fine, but the price difference for solid copper is usually small.

Q4. Can I use Cat 6 cable with my existing Cat 5e equipment?

Yes. Cat 6 is backward compatible with Cat 5 and Cat 5e equipment. Using Cat 6 cable with older equipment doesn’t give you Cat 6 speeds (the equipment still limits performance), but the cable works fine.

Q5. How long can my cable runs be?

Standard Ethernet limit is 100 metres total run length including patch cables. For 10 Gbps speeds on Cat 6, the practical limit drops to around 55 metres. Always design with margin, runs near the maximum can have performance issues.
