Washer G.I 10mm & 8mm, Outer Diameter 24mm

Washer 10mm and 8mm GI. Made in China G.I 4.8

Dimensions for DIN125 Form A Washers

Specifications

Measure the size a washer

Parts that Require Matching with a Mating Item
It is important to note that when matching a washer with a screw or a bolt, the diameter of the shaft of the screw or bolt should be matched to the inner diameter of the washer. For example, a ¾-16 bolt should be matched with a ¾ washer.

M8 means 8mm

The defined diameter of metric bolts is actually slightly larger than the actual diameter of the bolt shaft. So an M8 bolt would have a shaft diameter that’s slightly under 8mm which means that the bolt should fit through an 8mm hole.

Purpose of a screw washer and nut.

Washers are used to distribute the load of a threaded fastener, such as a bolt or nut. Before a screw or bolt is driven into a surface, a washer may be placed in order to prevent looseness and provide protection. This also prevents the bolt head and nut from damaging the surfaces of the two fastened parts.

How many washers per bolt?

How many washers per bolt? Typically, a washer is only used on the nut side of a bolt and nut assembly but more can be used depending on the application.

Is M10 the same as 10mm?

Steel bolt with M10 metric thread. Metric threads are designated with a capital M plus an indication to their nominal outer diameter and their pitch: This bolt is M10 x 1.5 – which means the outside diameter is 10mm and the threads are 1.5mm apart (the most common thread pitch for M10).

Use of washer with screw or nut

Place the washer on the side that will turn and drive into the surface. This is typically the nut side. Place the washer on the bolt side. Place the washer on the side that will drive into the surface during tightening.

Gratefulness

Thank you for choosing us! We are dedicated to giving you the best products possible. If you have any questions, feel free to get in touch.
