Trane Refrigerant Filter Element X09130157-001
The Trane X09130157-001 is the genuine oil and refrigerant filter element used on Trane RTAA series air-cooled screw chillers. It captures particulates and contaminants in the oil and refrigerant circuit, protecting the screw compressor rotors, bearings, and oil pump from premature wear. A critical service consumable for facility teams maintaining medium and large tonnage Trane chillers in commercial and industrial sites.
Key Features
- Trane RTAA filter element. Engineered for the exact flow path, micron rating, and pressure drop the RTAA platform was designed around. No guesswork on whether an aftermarket filter will starve the oil pump or bypass under load.
- Filters at fine micron level. Captures the wear particles, varnish, and debris that screw compressor oil naturally generates over time. Clean oil is the single biggest factor in screw rotor longevity.
- Cross-referenced part numbers. Listed under ELM0016E, X09130157-001, 9130157001, and FLR-5917, so technicians can match it to chiller log books and parts manuals without confusion.
- Confirmed dimensions for direct fitment. Total length 55 mm seal area, OD 78.5 mm, ID 43.2 mm. Drops into the existing housing with no shimming or modification.
- Built for high system pressures. Constructed to handle the operating pressures and temperatures inside an RTAA refrigerant and oil loop without collapsing.
The Filter Most Chiller Plants Underestimate
Screw chillers like the Trane RTAA do not fail randomly. They fail because oil quality drops, debris circulates, and the rotors lose their tight tolerance. The X09130157-001 oil and refrigerant filter element sits at the centre of preventing that. It is a small consumable with an oversized impact on chiller life, and it is one of the most common parts neglected during service rounds in Saudi facilities.
When this filter loads up, the pressure drop across it climbs. Oil flow to the bearings drops. The compressor temperature rises. Rotor clearances shift. Eventually, the chiller either trips on a high differential, loses capacity, or the compressor begins to wear in ways that show up months later as a noisy startup or a failed run. The filter is cheap. The cascade after a missed change is not.
Why the Genuine Element Matters Here
Generic substitutions look identical until you measure them. The seal lengths differ. The ID changes by a millimetre. The media micron rating drifts. On an RTAA chiller, those small changes either bypass dirty oil into the compressor or pinch flow until the differential alarm trips. The genuine X09130157-001 is built to the dimensions and specification the chiller’s oil management was originally engineered for, which is why most service teams maintaining critical cooling assets refuse to substitute on this particular part.
Real-World Service Context
A maintenance window on an RTAA chiller usually involves an oil sample, a filter change, and a leak check. Saudi sites running these chillers in shopping malls, hotels, hospitals, and industrial plants typically schedule the change annually or based on operating hours. After unusual events such as a compressor over-temperature, a burnout on a paired circuit, or a refrigerant contamination event, the filter should be changed immediately and rechecked at short intervals. Buying the genuine element means the next chiller log entry shows a part number that matches the manual, which is what auditors and warranty claims expect to see.
Stocking and Service Planning
Facility teams in Riyadh, Jeddah, and the Eastern Province typically keep at least one of these on the shelf per chiller. Lead times on genuine Trane spares can be unpredictable, and an unplanned chiller stop during peak summer load is not the moment to discover the filter is on backorder.
Applications / Best Use Cases
- Trane RTAA series air-cooled screw chillers, scheduled service
- Oil change and oil sampling routines on screw compressors
- Post contamination event cleanup on RTAA refrigerant and oil loop
- Commercial buildings, district cooling plants, and industrial process cooling using Trane RTAA platforms
- Preventive maintenance kits for chiller service contractors
Technical Specifications
| Specification | Detail |
| Manufacturer | Trane |
| Primary Part Number | X09130157-001 |
| Cross References | ELM0016E, 9130157001, FLR-5917 |
| Type | Oil and Refrigerant Filter Element |
| Format | LG 6 inch element |
| Total Length (TL) | 55 mm |
| Outer Diameter (OD) | 78.5 mm |
| Inner Diameter (ID) | 43.2 mm |
| Weight | 0.450 kg |
| Fits Models | Trane RTAA series chillers |
| Condition | New
|
Why Buy Trane Refrigerant Filter Element X09130157-001 From Cool.sa
Cool.sa is the practical choice for Saudi Arabia’s HVAC and chiller service market. We supply genuine Trane chiller spares with documented part numbers, fast nationwide delivery, and technical staff who understand RTAA, RTHD, and CenTraVac platforms. Whether you are running a single chiller in a private facility or a fleet of units across a retail portfolio, Cool.sa keeps you stocked with the parts that matter most during the Saudi cooling season.
FAQ
1. How do I confirm this is the right filter for my Trane RTAA?
Match the genuine part number on your chiller’s service manual or existing filter housing label. The X09130157-001 cross-references to ELM0016E, 9130157001, and FLR-5917. If unsure, share your chiller’s model and serial and our team can verify.
2. How often should I replace the X09130157-001?
Most service contracts call for an annual change tied to oil sampling. After abnormal events such as high oil temperature alarms or a recent compressor incident on a paired circuit, replace it immediately as part of the cleanup.
3. Is this a genuine filter or aftermarket?
Cool.sa supplies the genuine Trane element under the original Trane part number. We can advise on quality aftermarket equivalents if requested, but the SKU listed here is the genuine Trane component.
4. Can the same filter be used on RTAC, RTHD, or RTWD chillers?
No, different Trane screw chiller platforms use different filter elements. The X09130157-001 is specific to RTAA family applications. Always confirm against the chiller’s spare parts list before ordering.
5. Do I need to change the oil at the same time?
Best practice on a screw chiller is to combine the filter change with an oil sample at minimum. A full oil change is recommended when the sample shows acidity, high water content, wear metal increases, or viscosity drift outside the specified range.
